High Voltage MCU series (45KW-70KW)

High Voltage MCU series (45KW-70KW)

$5,150.00 USD
$5,150.00 USD
Sale Sold out
Nominal voltage: 415VDC
Nominal power: 45kW
Peak power: 112.5kW
Continuous current: 180Arms
Peak current: 480Arms@30s
Voltage range: 295-480VDC
Working ambient Temperature: -40~85℃
Cooling type: Water cooling
Max. Efficiency  Point: 98%
Position Sensor Type: Rotary Transformer
IP Grade: IP67
Weight: ≤10.0kg
Max. dimension: 320*300*117mm

Materials and care

Upgrade to Eco-Friendly Lead-Free Components Meeting ROHS Standards for Industry Sustainability.
